QuickJack 6000TL 6,000 lb Portable Low-Rise Vehicle Lift
$1,925.00
$899.00
The QuickJack 6000TL is a 6,000 lb capacity portable low-rise vehicle lift designed for automotive maintenance, wheel and tire service, brake work, detailing, and general underbody access. Its portable dual-frame configuration provides lifting capability without requiring permanent posts or a fixed floor-mounted lift.
The 6000TL features automatic dual-position safety locks, a pressure-compensated hydraulic flow divider, reinforced cross members and pivot joints, durable urethane wheels, and a portable hydraulic power unit with a one-handed pendant control.
The lift has a 3-inch lowered frame height for access beneath compatible low-clearance vehicles. Maximum frame height is approximately 20.25 inches, while the included lifting blocks provide up to 24 inches of maximum lifting height when properly configured.
Specifications:
Brand: QuickJack
Model: 6000TL
Manufacturer SKU: 5175729
Product Type: Portable Low-Rise Vehicle Lift
Lifting Capacity: 6,000 lb
Lowered Frame Height: 3 in
Maximum Frame Height: 20.25 in
Height With Small Blocks: 20.5 in
Height With Tall Blocks: 21.5 in
Maximum Height With Stacked Blocks: 24 in
Minimum Lifting Point Spread: 37 in
Maximum Lifting Point Spread: 60 in
Frame Length: 70 in
Frame Width: 11 in
Individual Frame Weight: Approximately 79 lb
Power Unit Weight Without Fluid: Approximately 27.3 lb
Power Unit Pressure Relief Setting: 2,400 PSI
Maximum Operating Pressure: 2,100 PSI
Hydraulic Fluid Capacity: Approximately 2.1 qt
Operating Temperature Range: 32°F to 104°F
Safety System: Automatic Dual-Position Mechanical Locks
Hydraulic System: Pressure-Compensated Flow Divider
Power Unit: Portable Hydraulic Power Unit with Pendant Control
